Tektronix MDO4104C Mixed Domain Oscilloscope
Tech Support
(800) 404-2832
With Every
Rental
Worldwide
Delivery
Larger
SKU:
TEKT-MDO4104C
Categories
Mixed Domain Oscilloscopes
Oscilloscopes
Documents
Datasheet
Print
Email
The Tektronix MDO4104C Mixed Domain Oscilloscope provides 4 analog channels of 1 GHz bandwidth with a 350 ps rise time. This unit offers an RF channel frequency range from 9 kHz to 3 GHz with Option SA3 or a 9 kHz to 6 GHz with option SA6. The MDO4104C supplies a reputable Tektronix oscilloscope paired with an expandable platform and customizable to testing needs. To tackle complex design challenges, utilize the 16 logic channels, 50 MHz arbitrary/function generator, protocol analysis, and integrated true hardware 3 or 6 GHz spectrum analyzer. See the real-time effects of time domain signals on system EMI emissions. Discover the true behavior of a wireless setup with the complete system view the Tektronix MDO4104C provides through analog, digital and RF data time-synchronized to understand its true behavior. For issues with managing multiple instruments on a bench, the MDO4104C eliminates the need to manage various devices at once with its 6-instruments-in-1 capability.
The MDO4000C series features a sophisticated interface with diverse applications. Digital phosphor technology with FastAcq provides you with fast insight into the real operation of your device. Its fast waveform capture rate – greater than 340,000 wfms/s - gives you a high probability of quickly seeing the infrequent problems common in digital systems: runt pulses, glitches, timing issues, and more. To further enhance the visibility of rarely occurring events, intensity grading is used to indicate how often rare transients are occurring relative to normal signal characteristics. There are four waveform palettes available in FastAcq acquisition mode. The MDO4104C models possess a spectrum analyzer, logic analyzer and protocol analyzer, as well as the new addition of the arbitrary/function generator.
The Tektronix MDO4104C is the fourth model in the
Tektronix MDO4000C Mixed Domain Oscilloscope Series
.
Specifications
Features
Applications
Options
Accessories
Standards
Videos
Features
4 analog channels
1 GHz, 500 MHz, 350 MHz, and 200 MHz bandwidth models
Bandwidth is upgradeable (up to 1 GHz)
Up to 5 GS/s sample rate
20 M record length on all channels
> 340,000 wfm/s maximum waveform capture rate
Standard passive voltage probes with 3.9 pF capacitive loading and 1 GHz or 500 MHz analog bandwidth
Specifications
Analog channels
4
Analog channel bandwidth
1 GHz
Rise time
350 ps
Sample rate (1 ch)
5 GS/s
Sample rate (2 ch)
5 GS/s
Sample rate (4 ch)
5 GS/s Without option SA3 or SA6
2.5 GS/s With option SA3 or SA6
Record length (1 ch)
20M
Record length (2 ch)
20M
Record length (4 ch)
20M
Digital channels
16
RF channels with MDO4MSO
1
Arbitrary Function Generator
outputs with MDO4AFG option
1
Spectrum analyzer frequency range
9 kHz - 3 GHz With Option SA3
9 kHz - 6 GHz With Option SA6
Applications
Options
Accessories
Standards
Media
RELATED PRODUCTS
Keysight MXR608A Oscilloscope | 6 GHz, 8 ch
Yokogawa DLM5058 Mixed Signal Oscilloscope | 500 MHz, 2.5 GS/s
Keysight CX3324A Device Current Waveform Analyzer
Tektronix MDO3000 Series Mixed Domain Oscilloscopes
Tektronix MSO58 Mixed Signal Oscilloscope 1 GHz
Rohde & Schwarz RTO2000 Oscilloscopes
LeCroy WaveRunner 620Zi Digital Oscilloscope
Yokogawa DLM 2054 500 MHz 16 Ch Digital, 4 Ch Analog Oscilloscope
AEMC OX 7104 III Handheld Oscilloscope
AEMC OX III Handheld Oscilloscope Series
Agilent 1134A InfiniiMax 7 GHz Active Probe
Fluke 190 Series II ScopeMeter Test Tools
Fluke 190-502 | 500 MHz 5 GS/s 2 channel
Fluke 196 2 Channel ScopeMeter
Fluke 199 Two Channel Scope Meter | 2 Ch, 200 MHz
Fluke 199B Two Channel Scope Meter 2 Ch, 200 MHz
Fluke 199C
Fluke 199C-S | 2 Ch, 200 MHz, 2.5 GS/s
Fluke i1010 AC/DC Current Clamp
Keysight 16534A 2 GSa/s 2-Channel 500 MHz BW Digitizing Oscilloscope Module
Keysight 16712A Timing Analysis Module 100 MHz / 500 MHz
Keysight 16851A 34-Channel Portable Logic Analyzer
Keysight DSO9104H High-Definition Oscilloscope
Keysight Infiniium DSO9104A-100 Oscilloscope
Keysight Infiniium S-Series Oscilloscopes
