The PAM-103 is a general purpose, broadband, high gain, benchtop amplifier. This preamplifier reduces floor noise and increases system sensitivity to low level signals during Electromagnetic Interference (EMC) testing.
The PAM-103 is primarily used for EMC radiated emissions testing. This preamplifier can be used during EMC testing for FCC, CISPR, EN, FAA and MIL-STD.
Specifications
Frequency: |
1 MHz - 1000 MHz |
Application: |
EMI / EMC Measurements |
Gain |
33 dB |
Gain Flatness |
± 3 dB |
3 dB Bandwidth |
500 kHz,1200 MHz |
P1dB |
+4 dBm |
Impedance I/O |
50 Ohms |
Connector Type |
BNC (f) |
Power: |
12 VDC, 0.7 A NimH |
Battery Pack |
2 x 6 V NimH Battery packs |
Size: |
(L x W x H) 7.5" x 5" x 3" (9 x13 x 7.6 cm) |
Weight: |
3.3 lbs. (1.5 kg) |
