Operating temperature |
-20 to 60°C (-5 to 140°F) |
Weight |
12.1 oz (0.34 kg) |
Source/power & measure 2-wire transmitters |
Accuracy:
≤ ± (0.025 % of span at 4 mA & 20 mA) (±0.005 mA)
≤ ± (0.05 % of 24 mA Span) (±0.012 mA) |
Range and resolution: 0.000 to 24.000 mA or -25.00 to 125.00% of 4-20 mA |
2-wire transmitters |
Accuracy:
≤ ± (0.025 % of span at 4 mA & 20 mA) (±0.005 mA)
≤ ± (0.05 % of 24 mA span) (±0.012 mA) |
Voltage burden: ≤ 2V at 20 mA |
Overload/current limit protection: 24 mA nominal |
Loop voltage limits: 2 to 100 VDC |
Dimensions
(L x W x H) |
5.63 x 3.00 x 1.60 in
143 x 76 x 41 mm |
Read mA |
Range and resolution: 0.000 to 52.000 mA or -25.00 to 300.00% of 4-20 mA |
Accuracy:
≤ ± (0.05 % of 24.000 mA) (+0.012 mA)
≤ ± (0.05 % of 52.000 mA) (+0.026 mA) |
