Compressed Air |
Clean, Dry Air (CDA) |
- Filtered to 5μ particulate contamination
- Oil Content: < 0.10 ppm by weight and filtered to 0.01μ oil contaminants
|
Input Air Dewpoint |
Contaminants -40°C dewpoint or dryer@90PSI (6.2 BAR) |
Input Air Pressure |
90 to 120 PSIG (6.2 to 8.3 BAR) |
Input Air Flow |
7 to 15 SCFM (3.3 to 7.0 l/s) 14 SCFM nominal |
Input Air Temperature |
+15° to +25°C, +22°C nominal |
Operating Temperature Environment |
+15° to +28°C, +23°C nominal |
Operating Humidity |
0 to 60% RH, 45% nominal |
