Fluke Omniscanner 2 LAN Cable Analyzer
Discontinued
The Microtest/Fluke Omniscanner 2 is a leading producer of network test and measurement products and network storage and appliance servers. The OMNIScanner LT certifies Cat 5/5e/6 cabling. Accuracy is guaranteed by a fully digital frequency domain DSP design. Supporting patent-pending S-Band diagnostics, it provides the fastest autotests and a graphical interface.
Microtest/Fluke Omniscanner 2 Supported Tests:
- NEXT, NEXT @ Remote
- Wire Map
- Length
- Impulse Noise
- Propagation Delay
- Return Loss (RL), RL @ Remote
- Delay Skew
- Attenuation
- Attenuation-to-Crosstalk Ratio (ACR), ACR @ Remote
- Power Sum ACR, PSACR @ Remote
- ELFEXT, ELFEXT @ Remote
- Power Sum ELFEXT, PSELFEXT @ Remote
- Power Sum NEXT, PSNEXT @ Remote
Microtest/Fluke Omniscanner 2 Cables Types:
- Shielded and Unshielded Twisted Pair (STP & UTP) LAN Cabling:
- TIA Cat 3, 4, 5, 5E & 6: 100W
- ISO/IEC Class C & D: 100W & 120W
- Foil-Screened Twisted Pair (ScTP):
- TIA Cat 3, 4, 5, 5E & 6: 100W
- ISO/IEC Class C & D: 100W & 120W
- Shielded Twisted Pair (STP): 150W IBM Type 1, 6, & 9 (adapter required)
- Coax: RG-6, RG-58, RG-58 Foam, RG-59, RG-59 Foam Fiber
- Fiber: Multimode and singlemode fiber using fiber test accessories
Microtest/Fluke Omniscanner 2 Test Standards:
- TIA Cat 3 & 5E per Addendum #5 to TIA/EIA-568A
- TIA Cat 5 (new) per TIA TSB-95
- TIA Cat 6 per TIA Addendum #1 to TIA/EIA-568B (draft)
- ISO/IEC 11801 Class C & D (new)
- ISO/IEC 11801-2000 Class C & D (new)
- STP cabling, (IBM Type 1, 150 )
- IEEE 802.3 10BASE-T, 100BASE-TX, 1000BASE-T
- IEEE 802.5
SKU: MICR-OMNISCANNER
