Keysight 4935A Transmission Impairment Measuring Set

HP Agilent 4935A Transmission Impairment Measuring Set
Enlarge Image
Keysight 4935A
Request Quote Print Page

The 4935A is a Transmission Impairment Measuring Set (TIMS) which measures wideband data and voice impairments. The frequency range over which measurements are made is 20 Hz to 110 kHz, in steps of I, 10, 100, 1000, or 10,000 Hz. There are four permanently stored, fixed frequencies -404, 1004, 2804. and 2713 Hz. Any other four frequencies may be temporarily assigned and stored by the user.

Options:
Opt 001Rechargeable batteries
Opt 002Add P/AR measurement, delete noise-to-ground
Opt 003Add options 001 and 002
Transmission Impairment Measurement Set (TIMS)

Keysight 4935A Features
  • Basic analog tests to isolate faults and to qualify circuits for voice, data, and broadcast service
  • Compatible with the Bell standards (BSTR 41009) and IEEE standards (IEEE 743-1984)
  • Measurement: Level, frequency, circuit noise, noise-with-tone, signal-to-noise ratio, 3-level impulse noise (quiet or tone), noise-to-ground, P/AR (option)
  • Filters: C-message, 3 kHz flat, Program, 15 kHz flat, 50 kbit, 1010 Hz notch
