FLIR Gx320 Optical Gas Imaging (OGI) Camera

The FLIR Gx320 Optical Gas Imaging (OGI) Camera is part of the FLIR G-Series. The Gx320 has an IR resolution of 320 x 240, a detector pitch of 30 μm, and a spectral range of 3.2 µm - 3.4 µm. This model has a field of view of 24° × 18° (23 mm) and is ideal for detecting butane, methane, ethanol, ethylene, hydrocarbons, propane, and VOCs.

Reach out today to learn more about the Gx320.

Product Info Related Products

Model	Gx320
IR Resolution	320 × 240 thermal resolution (76,800 pixels)
Detector Pitch	30 μm
Accuracy	±1°C (±1.8°F) for temperature range 0°C to 100°C (32°F to 212°F) ±2% of reading for temperature range >100°C (>212°F)
Spectral Range	3.2 µm – 3.4 µm
Field of View	24° × 18° (23 mm)
Gas	Butane, Methane, Ethanol, Ethylene, Hydrocarbons, Propane, VOCs
Focus	Manual
Dimensions (L x W x H )w/ Lens	251.6 × 164.5 × 170.9 mm (9.9 × 6.48 × 6.73 in)
Weight	3 kg (6.18 lb.)
Temperature Range	-20°C to 350°C (-4°F to 662°F) Available sub ranges: -20°C to 10°C (-4°F to 50°F) -10°C to 25°C (14°F to 77°F) 10°C to 50°C (50°F to 122°F) 40°C to 85°C (104°F to 185°F) 70°C to 120°C (158°F to 248°F) 100°C to 160°C (212°F to 320°F) 130°C to 200°C (266°F to 392°F) 180°C to 260°C (356°F to 500°F) 240°C to 350°C (464°F to 662°F)
Thermal Sensitivity	<10 mK at 30°C (86°F)
