AMETEK Land Lancom 4 Portable Gas Analyzer

The AMETEK Land Lancom 4 Portable Gas Analyzer is a compact multigas analyzer capable of measuring up to eight flue gases in a range of combustion and emissions processes. The AMETEK Land Lancom 4 enables highly accurate spot and semi-continuous gas testing adaptable to a wide variety of applications – ensuring your plant maintains full compliance with safety and emissions requirements. Customizable to specific gas measurements and process stream conditions, the AMETEK Land Lancom 4's resilient stainless steel probe extracts the gas sample while advanced real-time processing techniques produce the highly accurate combustion and emissions calculations you need. Easy to service and maintain, Lancom 4 is the ideal choice for industries burning coal, natural gas, oil or biomass, including applications in glass, power generation, hydrocarbon processing, natural gas compressor stations, minerals and industrial boilers.

Product Info Product Options

Display:	Full function color LCD with backlight, wide QVGA display
Keypad:	Tactile membrane (integral with display) function keys and cursors
Indicators:	LED for ON (Power), Stand-by, Charge, Low Battery, Fault
Power Supply:	95-265 V AC, 50-60 Hz, 30 Watts. Battery, rechargeable lead-acid (internal). Typical 8 hour operation, dependent on options fitted
Ambient Temperature:	-5 °C to 45 °C (+23 °F to 113 °F)
Case:	Medium density blended polyethylene
Dimensions:	453 x 120 x 245 mm (17.8’’ x 4.7’’ x 9.6’’)
Weight:	6 kg (13 lb)
Standard Accessories:	Integral Water Catchpot and Filters
	Battery Charger Supply
	Data Logging
	Insight Data Acquisition Software (free download)
	Wake and Sleep facility (Semi-continuous monitoring)
	Carry Case
Options:	Min of 3 to max 9 gases in total, from a selection of 9 gases
	Probe length options - 0.3, 1.0, 1.5, 2.0, 3.0 m/1, 3.3, 5, 6.5, 10 ft
	Hose length options - 3 m/10 ft or 10 m/33 ft
	Draft Measurement
	Flow Measurement
	Smoke Measurement
	Analogue outputs (eight 4-20 m A outputs)
	Languages - English, French, German, Italian, Spanish & Chinese; others available
	External Printer

Monitoring of up 17 measurement parameters
Up to 9 gas measurements in a single instrument
High quality color display
Multiple language support
USB communications support
Weighs only 6 kg (13 lbs)
Robust, industrial design
Wake and sleep, semi-continuous operation mode
Range of user selectable options
Data acquisition & analysis software
Simple field upgrade
Meets ASTM D-6522 with dry sampler probe
Convenient catchpot - visible and accessible
Clip-in filters - quick to change

EPA Method 3/3A - DETERMINATION OF OXYGEN AND CARBON DIOXIDE CONCENTRATIONS IN EMISSIONS FROM STATIONARY SOURCES
EPA Method 6C - DETERMINATION OF SULFUR DIOXIDE EMISSIONS FROM STATIONARY SOURCES
EPA Method 7E - DETERMINATION OF NITROGEN OXIDES EMISSIONS FROM STATIONARY SOURCES
EPA Method 10 - DETERMINATION OF CARBON MONOXIDE EMISSIONS FROM STATIONARY SOURCES (INSTRUMENTAL ANALYZER PROCEDURE)

SKU: AMET-LANCOM-4
