| Model |
PG-350 |
Dimensions
(W x D x H) |
Without side guards: 260 mm x 520 mm x 260 mm (10.2" x 20" x 10.2")
With side guards: 300 mm x 520 mm x 260 mm (11.8" x 20.5" x 10.2") |
| Weight |
Approx. 13 to 15 kg (29 to 33 lb.) |
| Components measured |
Nox/SO2/CO/CO2/O2 |
| Type of analyzer |
5 component analyzer |
| Ranges |
Nox: 0 to 25/50/100/250/500/1000/2500 ppm
SO2: 0 to 50/100/200/500 ppm
CO: 0 to 60/100/200/500/1000 ppm
CO2: 0 to 10/20/30 Vol.%
O2: 0 to 5/10/25 Vol.% |
| Linearity |
±2.0% of the full-scale |
| Drift |
Nox, CO, CO2 & O2: ±1.0% per day of the full-scale
SO2: ±2.0% per day of the full-scale |
| Warm-up time |
Sample conidtioner: Approximately 3 minutes (with heated line approx. 1 h)
Analyzer: ±2.0% per 2 hours of the full-scale for the warm-up in 30 minutes |
| Sample gas flow rate |
Approximately 0.5 L/min |
| Working temperature range |
5°C to 40°C (41°F to 104°F) |
