ConcealFab 007640-060030 PIM Blanket

The ConcealFab 007640-060030 PIM Blanket has a low PIM metal foil interior and durable vinyl outer fabric layers. The 007640-060030 model has dimensions of 60 x 30 in (1.52 x 0.75 m) and 4 tie-down loops. The ConcealFab 007640-060030 PIM Blanket is the ideal RF barrier for a variety of testing requirements.

Product Info Related Products

Model	007640-060030
Series	Part of the 007640-xxxxx series of Pim blankets
Construction	Metal foil sandwiched between heavy duty vinyl outer fabric layers Nylon webbing tie-down loops provided at corners
PIM Performance	IM3 <-120 dBm when tested in accordance with proposed IEC 62037-8, far field test, 2x 20 W test tones, static test, vertical orientation
RF Attenuation	>10 dB (600 MHz to 2 GHz) >20 dB (>2 GHz)
Tie-Down Loops	4
Dimensions (L x W)	60 x 30 in (1.52 x 0.75 m)

60 x 30 in (1.52 x 0.75 m)
Can be deployed on rooftops (both in front of as well as behind base station antennas)
Low PIM
Integrated tie-down loops
Durable and weatherproof

SKU: CONC-007640-060030

ConcealFab 007640-060030 PIM Blanket
