TSI 3410 Dust Aerosol Generator

The TSI Model 3410 Dust Aerosol Generator disperses dry powders and test dusts for applications requiring stable, continuous, and accurate dosing. It supports particle sizes from 0.2 µm to over 100 µm and output concentrations from 50 mg/m³ to 160 g/m³, depending on model. The 3410U version handles poor-flow powders using a dosing ring, while the 3410L uses a toothed belt for a wider dosing range. Both versions use ceramic ejector nozzles for dispersion and support refill during operation.

Product Info Related Products

Output Concentration Range	50 mg/m³ – 20 g/m³
Output Mass Flow	0.05 – 20 g/h
Aerosol Flow Rate	8 – 35 L/min
Particle Size Range	0.2 to >100 µm (material-dependent)
Powder Feeding Method	Rotating dosing ring (for poor flow powders)
Reservoir Refillable During Operation	Yes
Dispersion Mechanism	Ejector nozzle with ceramic tube
Compressed Air Supply	1 – 6 bar (100 – 600 kPa)
Maximum Overpressure	50 mbar (0.5 kPa)
Power Requirements	100 – 260 VAC, 50 – 60 Hz
Dimensions (H × W × D)	260 × 320 × 400 mm (10.2 × 12.6 × 15.7 in)
Weight	10.4 kg (22.9 lbs)
