Tektronix TCP303 Oscilloscope Current Probe
- DC – 50 MHz
- Max DC + Peak AC Current: 15A
- Max Peak Pulse Current: 50A
Tektronix TCPA300 Current Probe Amplifier
- DC to 100 MHz maximum bandwidth
- Automatic control and onscreen scaling and units
- AC/DC input coupling
Tektronix TCP0020 Current Probe
- Easy-to-use design
- DC to >50 MHz bandwidth
- Core jaw diameter of 5 mm (0.2 in)
Fluke i5s AC Current Clamp
Tektronix TDP3500 Differential Probe
- Bandwidth: ≥3.5GHz
- Rise time: ≤140ps
- Attenuation: 5X
Agilent 1134A InfiniiMax 7 GHz Active Probe
- Supports differential and single-ended measurements
- Common mode rejection of the differential probe reduces the noise floor
- Flat frequency response to eliminate distortion
Yokogawa 701921 100 Mhz Differential Probe
- Test range: 700 V - 100 MHz
- Bandwidth of DC to 100 MHz
- Output voltage: ±7 V (DC or ACpeak)
Power Electronic Measurement LFR-1/15-B/500 Peak Current Probe
- Peak Current: 300A/3kA
- Bandwidth (-3dB): 0.15Hz - 1MHz
- Accuracy: ±0.3% (typ.)
Cal Test Electronics CT4198 Differential Probe
- Bandwidth: 100MHz
- Max. Differential: ±8kV
- Rise Time: 3.5ns
Yokogawa 700929 10:1 Probe
- Bandwidth: DC to 100MHz (-3dB)
- Attenuation ratio: 10:1
- Connector Type: BNC
Tektronix P6563A SMD Probe
- Bandwidth (-3dB): 500MHz
- Rise time: 800ps (typical)
- Attenuation: 20X
Fluke i40s-EL Clamp-on Current Transformer
- Up to 40A AC
- Max Conductor Size: 15 mm
- CT Compatibility: 1A & 5A secondary
Tektronix TPP0201 Passive Voltage Probe
- Bandwidth: DC - 200MHz
- Rise time: <2.3ns (typical)
- Attenuation: 10X
Fluke 80i-110s AC/DC Current Clamp DC - 1kHz/20kHz
- Current Ranges: 0 to 10A DC or AC peak 0 to 100A DC or AC peak
- 0 to 10A DC or AC peak
- 0 to 100A DC or AC peak
Probe Master 4234 Power Management Differential Probe
- Bandwidth up to 100 MHz
- Up to +/-1400V(DC+Peak AC) Differential and Common Mode
- Safety Certified Applications
Tektronix CT5 Current Probe
- 1.5 inch diameter conductors
- Measurements on bare conductors to 3000 V
- Nullifies Dc effects to 300 A with Dc Bucking Coil
Tektronix A622 AC/DC Current Probe
- Frequency range: DC - 100kHz
- Max input current: 100A peak
- Max conductor diameter: 11.8mm
Haefely PDP-8000 Differential Impulse Measurement Probe
- Divider Ratio: 1000:1
- Max Impulse Voltage: 8000V
- Impulse Duration: 20 ms
Tektronix TRCP3000 Current Probe
- Frequency range: 1Hz - 16MHz
- Peak current: 3000A
- Sensitivity: 2mV/A
Tektronix TAP1500 1.5 GHz Low Voltage Probe
- Competitive electrical performance
- Versatile mechanical performance
- Robust Design
Tektronix P7350SMA 5.0 GHz Differential Probe
- <100 ps Rise Time
- 5.0 GHz Bandwidth
- Dual SMA Inputs to Internal 50 Ω Termination Network
Tektronix P6209 Active Probe 4 GHz
Tektronix P7380A Differential Probe
Tektronix P7330 High Performance Differential Probe
- <100 ps Risetime (P7350 Guaranteed)
- 5 GHz to 3.5 GHz Bandwidths (Typical)
- Low Input Capacitance: <0.3 pF Differential (P7350 Typical)
Tektronix P7313 Z-Active Differential Probe 12.5 GHz
- High Bandwidth
- Excellent Step Response
- Low Loading
