| Model |
Model 2025 |
Model 2050 |
| Measurement Range |
0.100 to 25.4 mm (0.004 to 1.0 in.) |
0.254 to 50 mm (0.010 to 2.0 in.) |
| Repeatability |
±0.25 µm (0.000010 in.) |
±0.5 µm (0.000020 in.) |
| Linearity |
±0.9 µm (±0.000036 in.) |
±1.5 µm (±0.000060 in.) |
| Measurement Area Depth Of Field |
±.75 x 25 mm (±0.030 x 1.0 in.) |
±1.5 x 50 mm (±0.060 x 2.0 in.) |
| Laser Beam Velocity |
50 m/sec. (2,000 in./sec.) |
100 m/sec. (4,000 in./sec.) |
| Temperature Coefficient |
<0.2 µm/°C (<0.000004 in./°F) |
| Calibration |
Factory calibrated |
| Scan Rate |
100/sec |
| General Specifications |
| Operating Temperature |
7° to 36°C (45° to 97°F) at < 90% relative humidity |
| Storage Temperature |
-20° to 60°C (-4° to 140°F) |
| Dimensions (H x W x D) |
254 x 635 x 228 mm (10 x 25 x 9 in.) |
| Weight |
19.7 kg (43 lb.) |
| LaserSource |
HeNe gas laser; <1 mW output |
| Display |
177.8 mm (7 in.) capacitive touch |
| Power Requirements |
100 to 240 volts AC (+5% to -10%), 50/60 Hz (±2 Hz)100 watts total power |
