Image of Keysight 8168F Lightwave Tunable Laser Source

Keysight

Keysight 8168F Lightwave Tunable Laser Source

The Keysight 8168F Tunable Laser Source has a wavelength range of 1450 nm to 1590 nm. Every wavelength point generates a genuine single-mode laser line due to an integrated side mode filter, which also prevents any potential multi-moding. With its built-in software, this unit is capable of single or dual channel loss, return loss, and coupling ratio measurement. Output power and wavelength are independent from each other with the 8168F.

Product Info
Wavelength range 1450 nm - 1590 nm
Wavelength accuracy ±0.035 nm
Wavelength resolution 0.001 nm
Wavelength stability ±100 MHz
Output power -7 ... 7 dBm
Sidemode suppression ratio  50 dB
Maximum output power +8 dBm
Weight 18 kg (46 lb.)
Dimensions (H x W x D) 145 mm x 426 mm x 545 mm (6 x 17 x 21.6 in)
  • Straight contact output connector
  • Variabe attenuator
  • Tunning linearity ±1 pm possible
  • Auto realignment
  • Built-in sidemode filter for true single-mode operation over the full wavelength range
  • Output power and wavelength are selectable independent


SKU: AGIL-8168F-PKG02
