The A.H. Systems' SAS-521F-7 Bilogical Antenna is one of the latest antennas, providing an inexpensive solution to wide band applications. Whether testing inside a shielded enclosure or outdoors, this antenna will display efficient performance characteristics through the frequency range of 25 MHz to 7000 MHz.
AH Systems SAS-521F-7 Features
  • Hybrid Log Periodic- Biconical Antenna
  • Wide Frequency Range of 25 MHz- 7000MHz
  • Receive and Transmit
  • Individually Calibrated (1, 3, and 10 Meter calibration included, horizontal polarization)
  • FCC, MIL-STD, VDE and TEMPEST testing
  • Rugged Construction
AH Systems SAS-521F-7 Specs
Frequency Range: 25 MHz - 7000 MHz
Maximum Continuous Power: 400 Watts
Impedance: 50Ω
Max Radiated Field: 100 V/m
Connector: N-Type, female
Mounting Base: ¼ - 20 Thread, female
Physical Dimensions
Length: 39.0 in. (99.1 cm)
Width: 38.5 in. (97.8 cm)
Height: 22.2 in. (56.4 cm)
Weight: 4.5 lb. (2.04 kg)
