AH Systems SAS-563B Active Loop Antenna 1 kHz to 30 MHz

Rent AH Systems SAS-563B Active Shielded Loop Antenna 1 kHz to 30 MHz
Enlarge Image
Request Quote Print Page
Datasheet Specifications

This 12" Broadband loop antenna with preapmlifier is an excellent solution for magnetic field testing. A.H. Systems' designs, manufactures and delivers high performance Loop Antennas for a wide range of magnetic field testing.  Whether used in a set to measure shielding effectiveness per MIL-STD 285 and NSA 65-6, or individually to satisfy specific requirements, the Loop Antenna is an efficient, low cost solution.



Features:

  • Broad Frequency Range of 1 kHz to 30 MHz
  • Individually Calibrated (1 Meter calibration included)
  • FCC, MIL-STD, VDE and TEMPEST Testing
  • Rugged Construction
  • Battery Operated for Enhanced Portability



Specifications:

Frequency Range 1 kHz - 30 MHz
Impedance 50 W
Connector BNC, Female
Mounting Base ¼ x 20 Thread, Female
Physical Dimensions
Loop Diameter 12 in. (30.5 cm)
Weight 5.2 lb.'s (2.36 kg)
Supplied Accessories
Battery Charger (P/N: 2351)
