The Crystal XP2i Digital Pressure Gauge measures pressure from vacuum up to 15,000 psi, depending on range, with accuracy as high as ±0.02% of full scale or ±0.1% of reading, model dependent. It features a 5.5‑digit display, selectable pressure units, and data logging capacity of up to 32,000 points. The gauge supports RS‑232 communication, operates from −10 °C to 50 °C, and is rated IP66/IP67 for use in industrial and hazardous locations.
| Pressure Measurement Range | Vacuum to 15,000 psi (range dependent by model: 15, 30, 100, 300, 500, 1,000, 2,000, 3,000, 5,000, 10,000, 15,000 psi) |
| Measurement Accuracy | 0–20 % of range: ±0.02 % FS; 20–110 % of range: ±0.1 % of reading; vacuum: ±0.25 % FS (range dependent); optional S2: ±0.02 % FS; optional S5: ±0.05 % FS |
| Measurement Uncertainty Basis | Includes linearity, hysteresis, repeatability, temperature effects, and 1‑year stability |
| Resolution | Greater of 1 ppm of reading or model‑dependent minimum (down to 0.00004 psi / 2.5 Pa) |
| Display | 5.5‑digit LCD; single‑line 16.9 mm (0.67 in) or dual‑line 13.9 mm + 5.3 mm; update rate 4 readings/s (8 readings/s PSV mode) |
| Pressure Units | psi, inH₂O, inHg, mmHg, mmH₂O, kg/cm², bar, mbar, kPa, MPa, user‑defined units |
| Data Logging | 32,000 points; non‑volatile flash memory; interval 1 s - 18 h; minimum event 250 ms |
| Communication Interface | RS‑232 via DB‑9F |
| Operating Temperature | −10 °C - 50 °C |
| Storage Temperature | −40 °C - 75 °C |
| Power Supply | 3 × AA alkaline batteries; typical life 1,500 h; ultra‑low‑power mode >1 year |
| Intrinsic Safety / Certifications | ATEX / IECEx Ex ia IIC T4/T3 Ga; CSA Class I Div 1 Groups A–D; IP66/IP67 |
| Enclosure | Die‑cast aluminum; UV‑resistant polyester keypad; submersible to 1 m for 30 min |
| Wetted Materials | 316 stainless steel; Viton® O‑ring; silicone oil diaphragm seal |
| Physical Characteristics | Weight 562 g (19.8 oz); internal volume 295 mm³ (0.02 in³) |
