| Dimensions |
Pneumatic: 350 x 150 x 180 mm (13.8 x 5.9 x 7.1 in)
Hydraulic: 400 x 150 x 190 mm ( 15.7 x 5.9 x 7.5 in) |
| Weight |
Pneumatic: 3.6 kg (8 lb.) including battery
Hydraulic: 4.4 kg (10 lb.) including battery |
| Internal memory |
100,000 point data logging memory
Store user procedures and test results |
| Operating temperature |
-10° to 50°C (14° to 122°F) |
| Storage temperature |
-20° to 70°C (-4° to 158°F) |
| Ingress protection |
IP54 |
| Languages |
English
Chinese
Dutch
French
German
Italian
Japanese
Korean
Portuguese
Spanish
Turkish
Polish |
| Display |
112 mm (4.4 in) diagonal
320 x 240 pixels
LCD monochrome display |
