Thickness Range |
Resolution |
Velocity Range |
Pulse-Echo Mode
(P-E) |
(Pit & Flaw Detection)
Measures from 0.025 in. to 100 ft.
(0.63 mm to 30.48 M) |
+/- 0.001 in. (0.01mm)
+/- 0.0001 in. (0.001 mm) |
0.0122 to 0.7300 in./μs
309.88 to 18542 meters/sec |
| Pulse-Echo Coating Mode (PECT) |
(Material, Coating, Pit & Flaw Detection)
Material: 0.025 in. to 100 ft. (0.63 mm to 30.48 M) Coating: 0.001 to 0.100 in. (0.01 to 2.54 mm) |
+/- 0.001 in. (0.01mm)
+/- 0.0001 in. (0.001 mm) |
0.0122 to 0.7300 in./μs
309.88 to 18542 meters/sec |
| Pule-Echo Temp Comp Mode (PETP) |
(Pit & Flaw Detection)
Auto temperature compensation - measures from 0.025 in. to 100 ft. (0.63 mm to 30.48 M) |
+/- 0.001 in. (0.01mm)
+/- 0.0001 in. (0.001 mm) |
0.0122 to 0.7300 in./μs
309.88 to 18542 meters/sec |
| Echo-Echo Mode (E-E) |
(Through Paint & Coatings)
Measures from 0.100 to 6.0 in. (2.54 to 152.4 mm). Range will vary +/- depending on the coating |
+/- 0.001 in. (0.01mm)
+/- 0.0001 in. (0.001 mm) |
0.0122 to 0.7300 in./μs
309.88 to 18542 meters/sec |
| Echo-Echo Verify Mode (E-EV) |
(Through Paint & Coatings)
Measures from 0.100 to 1.0 in. (2.54 to 102 mm). Range will vary +/- depending on the coating |
+/- 0.001 in. (0.01mm)
+/- 0.0001 in. (0.001 mm) |
0.0122 to 0.7300 in./μs
309.88 to 18542 meters/sec |
| Coating Only Mode (CT) |
(Coating Thickness)
Measures from 0.0005 to 0.100 in. (0.0127 to 2.54 mm). Range will vary +/- depending on the coating |
+/- 0.001 in. (0.01mm)
+/- 0.0001 in. (0.001 mm) |
0.0122 to 0.7300 in./μs
309.88 to 18542 meters/sec |
