PMM BCICF-4 Injection Probe calibration fixtures are a part of the test equipment required by most of the Bulk Current Injection Test Procedure Specifications. The PMM BCICF-4 test fixture allows the user to quickly and easily calibrate the injection probe prior to performing the compliance testing.

The PMM BCICF-4 calibration fixture offers two important benefits:
  • Due to variable circuit impedances or resonances in cables and cable looms, the calibration fixture is used to establish the forward power into the injection probe needed to develop specified currents in the system under test.
  • The fixture can be used to measure the injection probes insertion loss.
