Tektronix P6248 Differential Probe, 1.7 GHz 1X Mode
Enlarge Image
Tektronix Test Equipment P6248
Manual

This oscilloscope probe is an accessory and is only available to rent with an oscilloscope.


  See All Oscilloscopes



The Tektronix P6248 is a high-bandwidth differential probe with the TEK-PROBE interface. The P6248 probe has a bandwidth of 1.5 GHz (1.7 GHz typical). The probe has low circuit loading, high common-mode rejection, and comes with accessories that accommodate a wide variety of applications.


The TEKPROBE interface is standard on Tektronix TDS series oscilloscopes. The Tektronix 1103 TEKPROBE Power Supply can be used for instruments without the TEKPROBE interface.

Tektronix Test Equipment P6248 Specs
DC Attenuation Accuracy ±2% for input voltages as follows: ±750 mV ( · 1) and ±7.5 V ( · 10)
±5% for input voltages as follows: ±850 mV ( · 1) and ±8.5 V ( · 10)
Maximum non-destructive input voltage ±25 V (DC + peak AC) between signal and common of the same channel
Differential signal range (DC coupled) ±8.5 V at attenuation setting of · 10
±850 mV at attenuation setting of · 1
Common-mode signal range (DC coupled) ±7 V
Output offset voltage ±10 mV (+ 20 ° C to+30 ° C, + 68 ° F to +86 ° F)
±50 mV (0 ° C to+60 ° C, + 32 ° F to + 122 ° F)
Rise time (probe only) < 265 ps
Common-mode rejection ratio 45 dB at 1 MHz in · 10
25 dB at 100 MHz in · 10
20 dB at 500 MHz in · 10
18 dB at 1 GHz in · 10
60 dB at 1 MHz in · 1
38 dB at 100 MHz in · 1
35 dB at 500 MHz in · 1
30 dB at 1 GHz in · 1
Bandwidth (probe only) DC to ≥1.5 GHz (-3dB)
