Amplifier Research FL7040 E-Field Probe Kit

2 MHz - 40 GHz | Probe, Interface & Cables

The Amplifier Research FL7040 Kit is an all-encompassing isotropic electric field probe kit tailored for EMC radiated immunity tests, covering a broad frequency range of 2 MHz to 40 GHz. The probe interface is neatly housed in a 19" wide, 2U high instrument case, and the AR FC7010, a 10-meter fiber optic cable set specifically designed for the FL7000 series probes. This comprehensive kit, with its capacity to measure electric fields from 2 to 1000 V/m and user-selectable X, Y, Z axes, is an essential asset for precise and reliable EMC testing.

Product Info Related Compliance Standards Related Products

FL7040: Electric Field Probe

Amplitude Accuracy (field aligned with sensor axes)	Without correction factors applied: ±1.0 dB @ 10 MHz
Amplitude Accuracy (field aligned with sensor axes)	With correction factors applied: Typical expanded measurement uncertainty (95% confidence interval): 0.8 dB, 2 MHz–1 GHz 1.4 dB, 1 GHz–40 GHz
Response Time/Sampling Rate (through FI7000)	20 msec up to 50 samples per second at FI7000, USB and GPIB only
Isotropic Deviation (measured at the orthogonal angle)	±0.5 dB @ 10 MHz, ±1.5 dB, 2 MHz–40 GHz (typical)
Operating Range	2–1000 V/m
Linearity, 2 to 1000 V/m	±0.5 dB
Temperature Stability	+0.5 dB over operating temperature range
Damage Level	1200 V/m CW
Ranges	Single continuous range
Data returned from probe	X, Y, Z axes, and composite
Power Requirements	Laser powered from FI7000 interface
Dimensions	Approx. 278 x 65 x 65 mm (10.95 x 2.6 x 2.6 in)
Weight	Approx. 150 g (5.3 oz)
Operating Temperature Range	10°C ... 40°C (50°F ... 104°F) @ 5% to 95% RH non-condensing
Fiber Optic Connectors	Two E2000 compact duplex connectors at 1 meter, includes fiber optic verification loop.

FI7000: Probe Interface
Input Voltage	90-260 VAC, 50-60 Hz
Input Current	0.2 - 0.6 A
Input Type	IEC inlet with filter
Laser	500 mW, 830 nm
Laser Shutdown Time	<1 msec after fiber disconnect < 250 msec after loss of communication
Connectors	(2) E2000 compact duplex female for probe communication and safety fiber loop (2) FSMA for fiber connection to FM7004A
Dimensions (W x H x D)	19.6 in x 5 in x 12 in
Weight	16 lbs

Contains internal microprocessor to provide linearization, temperature compensation, control, and communication
Laser-powered which allows for continuous operation
Communicates through glass fiber optic cables, up to 100 meters long
Kit includes FL7040 probe, FI7000 interface, and FC7010 fiber optic cables
