Rent Rohde & Schwarz ZVB20 Vector Network Analyzer 4 ports, 20 GHz
Enlarge Image
Rohde & Schwarz ZVB20
Request Quote Print Page
ZVB20 Datasheet
The Rohde & Schwarz ZVB20 Vector Network Analyzer 4 ports, 20 GHz covers the frequency ranges from 10 MHz to 14/20 GHz. It has been designed for universal measurements on passive and active components. The R&SZVB20 series greatly simplifies vector network analysis especially for multiport measurements and measurements on balanced devices. Featuring comprehensive measurement functions, excellent specifications, high measurement and data transfer speeds and remote-control capability, the analyzers of the R&SZVB20 series are an ideal choice for both development and production applications. The compact versions of the 14 GHz and 20 GHz two-port models leave ample room for test setups in the lab, featuring a height of only 24 cm and a depth of 42 cm.
Rohde & Schwarz ZVB20 Features
High performance for fast and reliable measurements
  • Reflectometers with separate measurement and reference channels
  • Parallel measurements on multiple ports
  • Data processing and transfer simultaneously with measurement
  • DC bias for active DUTs
Ergonomic user interface
  • User-configurable display of results
  • Manual operation support
  • Fast switching between instrument setups
  • Editor for trace mathematics
Advanced measurement functionality
  • Independent channels
  • Convenient marker and analysis functions
  • Integrated PC with Windows XP
Highlights of the R&S®ZVB in production
  • Integrated PC with Windows XP for automated procedures and data management
  • Optimization of test and production sequences
  • Mixer and harmonics measurements
