The Sonel KSF-320 is a SF6 gas thermal imaging camera that is equipped with a cooled detector to scan, analyze, and pinpoint gas leaks with precision. The KSF-320 is capable of monitoring and inspecting hard to reach areas that would be limited by contact measurement tools. KSF-320 gas thermal imaging cameras are widely used for gas leakage detection and thermograph applications. SF6 is commonly used in the electric power industry as an insulator and quenching medium for gas-insulated substations and circuit breakers. A key benefit that this Sonel unit provides is that systems under inspection do not have to be shut down for analysis. The KSF-320's LCD screen provides a thermal image and accurate temperature readings. All data is stored in a SD card for computer analysis.
Features
- Cooled QWIP detector, sensitivity <0.025° C, pinpoint gas leaks location quickly.
- SF6 Detection accuracy ≤ 0.001ml/s.
- Dual-application: Gas leakage detection and thermograph application.
- Temperature range: -20~500° C.
- Inspection without interrupted process.
- Interchangeable lenses available.
- Built-in 5.0 MP digital camera.
- Folding and 270° rotatable display.
Specifications
| Detector Data |
| Detector Type |
Cooled QWIP |
| Resolution |
320x256 |
| Pixel Pitch |
30 μm |
| Spectral Range |
10.3～10.7μm, wave crest 10.55 μm |
| Sensitivity/NETD |
<25mK @ 30° C |
| FOV/Min Focus |
10°× 7.5° / 0.5m Standard
20° x 15° / 0.25m Optional |
| Spatial resolution (IFOV) |
0.55mrad (10°× 7.5°) |
| Image Performance |
| Image Frequency |
60Hz |
| Focus |
Manual |
| Digital Zoom |
1～8 Continuous |
| Visual Camera |
5.0 Mega pixel |
| Spotlight |
10cd/m² |
| Image Display |
| Viewfinder |
0.6” color OLED, with magnification |
| Image Display |
5” , 270° tiltable LCD, 800×480 |
| Auto Image Adjustment |
Linear or histogram based |
| Manual Image Adjustment |
Level/Span |
| Image Modes |
Thermal image, Visual image, High-sensitivity |
Applications
- Electric Power Industry: Detect and visualize the SF6 and other harmful gases leaks and thermal imaging status from the insulation of electrical equipment, machines and high-voltage equipment switchgear; Failure diagnose.
- Petrochemical Industry: Oil pipeline check, material interface detection, heat leakage, insulation structure and power equipment detection.
- Fire Protection: Forest fire protection and latent fire source search, self-ignition prevention and detection of special material, and electric fire precaution detection.
- Medical Application: Accurately measures human body temperature and analyzes temperature field distribution.
- Building Industry: Humidity, air leakage and insulation defects detection.
- Other Applications: Research and development industry, automation industry, and preventive maintenance, etc.
