Image Quality |
IFOV (spatial resolution) |
0.6 mRad |
Image resolution (pixel) |
1024 x 768 (786,432 pixels) |
2048 x 1536 (3,145,728 pixels) (SuperResolution mode) |
Frame rate (@ max. image resolution) |
30 and 9 Hz |
SuperResolution & Dynamic SuperResolutin (resolution enhancement) |
Yes, MicroScan technology quadruples IR measurement pixels |
Subwindowing modes available - subwindowing options are not available on 9 Hz models: |
Option 1: 640 x 480 (60 fps)
Option 2: 384 x 288 (120 fps)
Option 3: 1024 x 96 (240 fps) |
Field of View (FOV) w/standard 30mm lens |
32.4° x 24.7° |
Thermal sensitivity (NETD) |
≤ 0.05°C at 30°C target temp (50 mK) |
Spectral range |
7.5 µm to 14 µm |
Focus System |
LaserSharp Auto Focus |
Yes |
Auto focus |
Yes |
Manual focus |
Yes, with the touch of a finger for tighter views |
EverSharp multifocal recording |
Yes, Multifocal recording captures images from different focal distances and combines them into one image displaying each object sharply for the best image quality |
Temperature Measurement |
Range |
-40°C to +1200°C (-40°F to 2192°F), High temperature option - request at time of order: up to 2000 °C (3632 °F) |
Accuracy |
± 1.5°C or ± 1.5% |
Correction functions |
LDC - Laser rangefinder based distance correction, emissivity (manual or material table) |
Transmissivity, ambient temperature, humidity (option) |
Data Storage and Image Capture |
Image/video storage |
SDHC memory card |
Interfaces for image/data transfer |
Supported in camera data ports: Image transfer: SD card, USB 2.0, video output DVI-D (HDMI). GigE vision and RS232 available in 2015 |
SmartView software: SD card. USB 2.0, GigE Vision and RS232 available in 2015 |
General Specifications |
Laser distance meter |
Accuracy: ± 1.5 mm
Range: 70 m (230 ft)
Wavelength: 635 nm (red)
Laser class: 2 |
Display |
Extra-large 5.6" color TFT display, 1280 × 800 pixel resolution, Suitable for daylight operation |
Geo-localization |
Built-in GPS for geo-referencing |
Digital visible light camera |
Up to 8 megapixel resolution for image and video recording |
Digital zoom |
Up to 32x digital zoom |
Text annotation |
Yes |
Voice annotation |
Yes |
Audio |
Integrated microphone and loudspeaker for voice annotations |
A/D conversion |
16 bit |
Power supply |
External: 12 VDC - 24 VDC
Battery: Standard Li-Ion video camera battery |
Replaceable Smart Batteries with LED level indicator |
Two |
Operating temperature |
-25°C to +55°C (-13°F to 131°F) |
Storing temperature |
-40°C to +70°C (-40°F to 158°F) |
Humidity |
Relative humidity 10% to 95%, non-condensing |
Shock |
Operational: 25G, IEC 68-2-29 |
Vibration |
Operational: 2G, IEC 68-2-6 |
Protection class |
IP54 |
Ergonomics |
Camcorder w/ handle |
Viewfinder |
Tiltable LCoS color viewfinder display, 800 × 600 pixel resolution |
Dimensions (with standard 1.0/30 mm lens) |
210 × 125 × 155 mm (8.25 x 4.9 x 6.1 in) |
Weight (with standard 1.0/30 mm lens) |
1.95 kg (4.3 lb) |
Measurement functions (selection) |
Multiple measurement spots & Regions of Interest (ROIs), hot/cold spot detection, isotherms, profiles, differences |
Automatic functions (selection) |
Focus, image, level, range, NUC, lens recognition, image optimization, alarm sequence |
SmartView software |
Yes |
Supported languages |
Czech, Dutch, English, Finnish, French, German, Hugarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese and Turkish. |
