Amplifier Research 1000TP2G8 TWT Amplifier 2.5GHz

Amplifier Research 1000TP2G8 TWT Amplifier 2.5GHz – 7.5GHz, 1000 Watts

The Amplifier Research 1000TP2G8 TWT Amplifier is a self-contained, forced air-cooled, broadband traveling wave tube (TWT) microwave amplifier designed for pulse applications at low to moderate duty factors where instantaneous bandwidth and high gain are required. A reliable TWT subsystem provides a conservative 1000 watts minimum peak RF pulse power at the amplifier output connector. Stated power specifications are at the fundamental frequency.

The Amplifier Research 1000TP2G8's front panel digital display shows forward and reflected average power output or forward and reflected peak power, plus extensive system status information accessed through a series of menus via soft keys.

Advanced Amplifiers AA-28G-400 Solid State CW/Pulse Amplifier

2.0 - 8.0 GHz
400 W
56 dB min

IFI T2618-50 Millimeter TWT Amplifier | 18 – 26.5 GHz, 50 W

Broadband, instantaneous frequency range
Constructed with modular design
High reliability and rugged construction

Advanced Amplifiers AA-28G-500-GT TWT Pulse Amplifier

2.0 - 8.0 GHz
500 W
56 dB min

Advanced Amplifiers AA-118G-50 Solid-State High Power Amplifier

1.0 - 18.0 GHz
50 W
47 dB min

IFI T251-500A TWT Amplifier | 0.8 GHz – 2.5 GHz, 500 W

Digital display monitors: collector current, collector voltage, helix current, helix voltage, forward rf power, reflected rf power, filament hours, beam hours
Status indicators: power on, standby, RF on/operate
Faults: helix overcurrent, VSWR overload, thermal overloads, air flow, collector overcurrent

IFI T188-500 High Power Amplifier | 7.5 – 18 GHz, 500 W

Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
Status Indicators: Power On, Standby, RF On/Operate
Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent

CPI PTC6382 TWT Amplifier

Frequency Range: 12.4 - 18.0GHz
Output: 4kW (Typ.), 66dBm
Duty Cycle: 6%, Pulse Length: 0.2 - 20μs

IFI S31-500 Solid State RF Power Amplifier 800 MHz - 3 GHz, 500 Watts

VSWR Reflected Power Protection, the unit operates without damage or oscillation into any magnitude of phase or load impedance, Open and Short Circuit Protection.
Alternate Prime Power (specify at time of order)
GPIB IEEE 488 and RS232 Remote Control

IFI T2618-40 Millimeter TWT Amplifier, 18 GHz - 26.5 GHz, 40 Watts

VSWR power protection allows the unit to operate without oscillation or damage
Records beam/filament elapsed time in hours
Features RF safetylock

IFI T188-300 TWT Amplifier | 7.5 GHz – 18 GHz, 300 W

Frequency Range: 7.5-18GHz
Min Power Out: 300 Watts
Min Sat Gain: 55dB

Advanced Amplifiers AA-2.58G-2KW-PT Pulsed TWT Amplifier

2.5 to 8.0 GHz
2000 W
Input power: 120 or 240 VAC (50 - 60 Hz)

IFI GT251-500A CW/Pulse TWT Amplifier 1 GHz - 2.5 GHz, 500 Watts

Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
Status Indicators: Power On, Standby, RF On/Operate
Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent

Advanced Amplifiers AA-818G-400-GT TWT High Power Amplifier

7.5 - 18.0 GHz
400 W
56 dB min

Amplifier Research 200T1G3 TWT Amplifier .8 GHz - 2.8 GHz 200W

800 MHz - 2.8 GHz
200 W
CW Amplifier

IFI T186-50 TWT Amplifier | 6 GHz – 18 GHz, 50 W

Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
Status Indicators: Power On, Standby, RF On/Operate
Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent

Amplifier Research 60S1G6 Microwave Solid State Amplifier 0.7 - 6.0 GHz, 60W

700 MHz - 6 GHz
60 W
CW Amplifier

IFI T2618-10 TWT Amplifier 18 GHz - 26.5 GHz, 10 Watt

Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
Status Indicators: Power On, Standby, RF On/Operate
Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent

Advanced Amplifiers AA-618G-300-T TWT Pulse Amplifier

6.0 - 18.0 GHz
300 W
54 dB min

IFI T82-500 TWT Amplifier, 2 - 8GHz, 500W

Solid state power supply
Instantaneous broadband frequency range
Modular design, rugged construction, force air cooling

CPI PTC6358 Pulse TWT Amplifier

Frequency Range: 7.5 - 18GHz
Output: 2kW (typ.), 63dBm
Duty Cycle: 6%, Pulse Length: 0.2 - 100μs

IFI T186-60 TWT Amplifier 6 GHz - 18 GHz, 60W

Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
Status Indicators: Power On, Standby, RF On/Operate
Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent

Exodus AMP2065B Solid State RF Amplifier | 6 GHz - 18 GHz, 300 W

Class AB linear GaN hybrid design
Instantaneous ultra-wide bandwidth
Solid-state TWT replacement

Advanced Amplifiers AA-118G-20 Solid State Amplifier

1.0 - 18.0 GHz
20 W
43 dB min

IFI T42-200 TWT Amplifier 2 GHz - 4 GHz, 200 Watt

Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
Status Indicators: Power On, Standby, RF On/Operate
Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent

IFI T-1000 Series High Power, RF Microwave, TWT Amplifiers

Input/output Impedance: 50 ohms
RF Input/ Sample Connectors: Type N Female, unless specified otherwise
RF Output Connector: Type 716 Female up to 7.5 GHz, 4 – 8 GHz is WRD350 8 – 12 GHz is WR90, 12 – 18 GHz is WR62, 7.5 – 18 GHz is WRD750, 6.5 – 18 GHz is WRD650 Other

Power (Fundamental), Peak Pulse, @ Output	Nominal, 1800 watts Minimum, 1000 watts
Flatness	±7 dB maximum, equalized for ±3 dB maximum at rated power
Frequency Response	2.5–7.5 GHz instantaneously
Input for rated Output	1.0 milliwatt maximum
Gain (at maximum setting)	60 dB minimum
