| Inputs |
2, 4, 6, 8 channels. Up to 8 BNC connectors, built-in IEPE current source, single-ended or differential, AC, DC coupling, 150 dBFS dynamic range, dual 24-bit A/D converters, input range ±20 Volts |
| Output |
1 LEMO connector, 100 dB dynamic range, 24-bit A/D converter |
| Tacho |
1 LEMO connector: Tachometer Type 1 and 2 share one LEMO connector and can be selected by the software Interface |
| Ports |
100 Base-T Ethernet, Wi-Fi, GPS, Mini-USB 2.0, SD Card, Audio input and output, CAN-Bus |
| Maximum Sampling Rate |
102.4 kHz simultaneously for all inputs |
| LCD |
7” color TFT WVGA display 800x480 resolution with P-Cap touch screen, 1300 NITS |
| Dimensions |
229 x 172 x 65.5 mm (L X W X H) |
| Weight |
1.96 kg including battery |
| Power |
Power Input: DC power 15 V (±10%)/3A
Max Power Consumption: 14 watts, 8 watts with LCD off
Battery Operations: 6-8 hours |
| Typical Real-time Analysis Functions |
Math (+,-,*, /), integration, differentiation, FFT, averaging, windowing, auto power spectra, cross spectra, FRF, coherence, real-time filters, RMS, octave, order tracking, swept sine, limiting, alarm/abort and more. |
| Vibration Data Collection Functions |
RMS, true-RMS, overall-RMS, waveforms, spectrum, demodulated spectrum, trending and alarm, 2 plane balancing. Measure acceleration, velocity, displacement and tachometer. |
