| Sensor input |
4-channel |
| Resolution |
12800 FFT lines |
| Frequency |
80kHz Fmax |
| Acceleration |
3-axis |
| Compatible sensor types |
Accelerometer, velocity & displacement |
| AC coupled range |
16 V peak-peak Allows for ± 8 V sensor output swing (± 80 g) |
| DC coupled ranges |
0 to 20 V, -10 to 10 V, -20 to 0 V |
| Connectors |
2 x LEMO connectors for CH1 & CH2+
1 X LEMO connector for Tach/Keyphasor
SCOUT240-IS includes a CH 2..4 breakout cable. |
| Analog to digital conversion |
24-bit ADC |
| Sensor excitation current |
0 mA or 2.2 mA (configurable), 24 V maximum
2.2 mA powers IEPE/ICP-type sensors |
| Sensor detection |
Measures sensor bias voltage
Warns if short circuit or not connected |
