The Magna Power TSD1200-64 Programmable DC Power Supply 600 Volts, 128 Amps provides a high voltage and current range. The TS Series IV covers voltages up to 600 Vdc and current levels up to 16 Adc. This model is the TSD600 connected in parallel to provide the high current. In addition, there are several special low voltage high current models, enabling a more cost-effective solution for these requirements.

All TS Series IV power supplies come standard with isolated 37-pin external I/O, RS232, Remote Interface Software, IVI drivers for integration into a variety of programming environment Three front panel types are available for maximum application flexibility. The A Version provides front panel control and calibration, start and stop buttons, and a digital display for voltage and current. The D Version front panel adds a 10-key digital front panel entry, memory sequencing, and modulation capabilities for non-linear output profile emulation.

Options:
  • 208/240 Vac Single-Phase Input (SP) (5 kW Only)
  • Cabinet and Integrations (+CAB1, +CAB2, +CAB3)
  • High Isolation Output (+ISO)
  • High Slew Rate Output (+HS)
  • IEEE 488.2 GPIB Interface (+GPIB)
  • LXI TCP/IP Ethernet Interface (+LXI)
  • Photovoltaic Power Profile Emulation (+PPPE)
  • RS-485DSS Interface (External) (+RS485)
  • UID47: Universal Interface Device (+UID)
  • USB Edgeport Interface (External) (+USB)
  • Water Cooling (+WC)
