ITECH IT6018C-1500-40 Power Supply | 1500 V

The ITECH IT018C-1500-40 is a high-performance electronic testing instrument designed for precision measurement and simulation tasks in R&D, production, and quality assurance environments. With power output capability of up to 1500 W and 40 A with an 18 kW power capacity, it can handle a wide range of test scenarios for power electronics. The ITECH IT018C-1400-40 is programmable and provides friendly user interfaces with options such as USB, LAN, GPIB, and RS232 for remote control and data logging.

Product Info Related Products

Dimensions (W x L x H)	19.02 x 31.56 x 5.96 in (48.3 x 80.1 x 15.1 cm)
Weight	88.2 lb. (40 kg)
Current	-40 – 40 A
Max. Power	18 kW
Voltage (Rated Value Range)	0 – 1500 V
Resistance	0 – 1Ω
Operating Temperature	0°C – 50°C (32°F – 122°F)
Storage Temperature	-10°C – 70°C (14°F – 158°F)
Power Factor	0.99
Command Response Time	2 mS
Model	IT6018C-1500-40

Bi-directional source and regenerative sink
Standard built-in USB/CAN/LAN/digital IO interface, optional GPIB/analog & RS232
Full protections: support OVP, ±OCP, ±OPP, OTP, power down protection, anti-islanding protection
Support control loop priority mode setting, different loop speeds can be set
Partial pre-compliant with LV123, LV148, DIN40839, ISO-16750-2, SAEJ1113-11, LV124, and ISO21848 testing standards
Support photovoltaic I-V curves simulation function
Built-in function generator, supports arbitrary-waveform generating
Adjustable output impedance
Support multiple working modes, rising and falling time can be adjustable
Battery simulation function
Strong dynamic driving profile simulation function, up to 10,000,000 points
