Solmetric PVA-1500S PV Analyzer Test Kit

Larger

SKU: SOLM-PVA-1500S

Categories

Solar PV Analyzers

Documents

Datasheet

The Solmetric PVA-1500S PV Analyzer Test Kit is a comprehensive tool for photovoltaic (PV) performance modeling and I-V curve testing. The kit includes a 1500V I-V curve tracer, a wireless PV reference sensor, and PVA test loads. Key features include wireless irradiance, tilt, and temperature sensing, real-time data capture, and a database of 50,000 PV modules that updates automatically. The bright touchscreen display and 300-foot wireless connectivity enhance usability and convenience, making it ideal for professionals in the solar industry.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

General Information
Characteristic	Description
High-efficiency PV modules	Engineered to accurately measure high-efficiency as well as standard PV modules and strings.
User interface	Bright, colorful graphics and touch screen controls for operator efficiency, ease-of-use, and in-field analysis. Runs on user's standard Windows laptop or tablet.
Wireless interfaces	Wireless interface between your PC and the I-V Measurement unit and between I-V unit and SolSensor.
Advanced PV models	Accurately predicts performance at both STC and current conditions. Checks your results immediately.
Equipment databases	Models for 50,000+ PV modules. Automatic updates.
High Throughput	Measure 1 MW in less than 2hrs at 110°F ambient.
Thermal Capacity	800 measurements at 25°C ambient, 250 measurements at 45°C ambient, in example PV systems with 1300V Voe, 16 strings per combiner, and 5 min. to move to next combiner.

I-V Specs
Parameter	Value
PV voltage range	0-1500V
Current range	0-30 A
Voltage accuracy (Oto 45°C ambient)	±0.5% ± 0.25 V
Current accuracy (o to 45°C ambient)	±0.5% ± 0.04 A
Resolution	25 mV, 2 mA
Current resolution	2mA
Measurement cycle time	4-5s typical, measurement-to-measurement
1-V sweep duration	0.05 - 2s. Typically 0.2s for PV strings.
1-V trace points	100 or 500, user selectable
Operating temperature (ambient)	-10 to +45°C
Battery life	8 hrs continuous operation, 1000 I-V curves
Protection features	Over-voltage, -current, -temperature, and reverse polarity
Safety	CAT III, 1500V
SolSensor Specs
Parameter	Value
Irradiance accuracy	±2% typical (100 to 1,500 W/m2, silicon cells)
Cell temp. accuracy	±2°C typical, SmartTemp method
Tilt accuracy	±2° typical (0-45°)
Measurement interval	lrradiance: 0.1 s Temperature: 1 s
Wireless range	1 00m (open line of sight)
Operating temp	-10 to +45°C
