Solmetric PVA-1500V3 PV Analyzer Kit
Tech Support
(800) 404-2832
With Every
Rental
Worldwide
Delivery
Larger
Categories
Solar PV Analyzers
Documents
Datasheet
Print
Email
The Solmetric PVA-1500V3 PV Analyzer Kit is a precise I-V curve tracer that offers incredible performance at both 1500 volts and 30 amps. The PVA-1500V3 PV Analyzer Kit uses a durable build to work in extreme conditions with an operating ambient temperature from -10°C to 45°C. The PV analyzer kit also has tilt sensing technology and advanced wireless irradiance to continue collecting detailed measurements in a variety of situations.
The Solmetric PVA-1500V3 PV Analyzer Kit offers ideal I-V curve measurement capabilities, providing reliable curve accuracy and detail on standard and high-efficiency modules. For the most difficult applications, the analyzer kit can also change the number of I-V curve points from 100 to 500 and provide even greater performance. The Solmetric PVA-1500V3 PV Analyzer Kit is also useful in any conditions thanks to a touch screen that shows colorful and brightened graphics that work on all Windows devices.
Specifications
Features
Applications
Options
Accessories
Standards
Videos
Features
Measures and displays I-V and P-V curves and key parameter values
Advanced built-in PV models provide immediate PV performance checking
Database of more than 70,000 modules, with automatic updates
Automates data management, analysis, and reporting
High thermal capacity: >800 measurements at 25°C ambient, 250 measurements at 45°C ambient
Clear, colorful, touch-capable software runs on your tablet or notebook PC, providing rich insight into PV performance
Accurately measures high-efficiency modules and strings
Wireless interfaces for faster setup, safer work environment, and freedom of movement during PV troubleshooting
Charging/charged LEDs
In-the-field firmware update ready
Specifications
General Specifications
PV Voltage Range
0 - 1500 V
Current Range
0 - 30 A
Voltage Accuracy
±0.5% ±0.25 V
Current Accuracy
±0.5% ±0.04 A
Resolution
25 mV, 2 mA
Current Resolution
2 mA
Measurement Cycle Time
4 - 5s typical
I-V Sweep Duration
0.05 - 2s
Typically 0.2s for PV strings
I-V Trace Points
100 or 500, user selectable
Protection Features
Over-voltage
Over-current
Over-temperature
Reverse polarity
Applications
Options
Accessories
Standards
Media
Instant Quote
RELATED PRODUCTS
Solmetric PVA-1500V2 PV Analyzer Kit
Solmetric PVA-1500S PV Analyzer Test Kit
Solmetric PVA-1000S I-V Curve Tracer 1000V
Tritec TRI-KA IV Curve Tracer Portable PV System Analysis Tool
HT Instruments I-V400 Photovoltaic (PV) Tester
Chauvin Arnoux GREENTEST FTV100 Solar Power Installation Analyzer
Dranetz Profitest PV Solar Panel Tester
HT Instruments Solar300N Single/3-Phase Photovoltaic Systems Tester
Keysight PV8922A Photovoltaic Array Simulator
Solmetric PVA-600 PV Analyzer
Solmetric PVA-600+ PV Analyzer Kit
Solmetric SunEye 210 Shade Tool
