| Number of channels |
4 |
| Data points |
1601 maximum |
| Parameters |
S11, S21, S12, S22, or user defined; analog voltage input; complex input and output impedance; complex input and output admittance; complex forward and reverse transmission |
| Scale resolution |
Log mag: 0.001 dB, linear mag: 1 pU
Phase: 0.01°, group delay: 0.001 ps
Time: 0.001 ms, distance: 0.1 mm
SWR: 1 pU
Power: 0.05 dB |
| IF bandwidth |
10 kHz, 1 kHz, 100 Hz, and 10 Hz |
| Internal 10 MHz time base stability |
Standard (1 Hz resolution)
With aging: <1 x 10-9/day
With temperature: <5 x 10-9 over 0˚ to 55˚C |
| Interface |
GPIB (IEEE 488.2) |
| Operating temperature |
0˚ to 50˚C |
Dimensions
(W x H x D) |
432 x 167 x 585 mm (10.5 x 17 x 23 in) |
| Weight |
27 kg (60 lb.) |
