Frequency Bands |
Broadband 1.8 - 19 MHz (-3dB)
Three narrow bands at 2 MHz, 5 MHz, and 10 MHz |
Time Correct Gain |
50 dB dynamic range, 20 dB per microsecond |
Gates |
3 fully adjustable |
Pulse Type |
dual 200 Volt square wave pulsers with
adjustable pulse width (spike, thin, wide)
and 50 Volt cut/boost for greater penetration |
Size (w x h x d) |
2.5 x 6.5 x 1.24 inches |
Battery Type |
3 x AA alkaline |
Velocity Calibration Range |
256 - 16,000 m/s (0.0100 - 0.6300 in/ms) |
