| Model |
ECHO PRO |
| DAC Points |
Up to 50 points, 110 dB dynamic range |
| Data Storage |
100,000 IDs onboard
Removable MicroSD card standard
Expandable to 32 Gb file types linear
2D
2D with custom point
3D
3D with custom point
Boiler with and without waveform storage options
32 character file name and 20 character longer I.D. strings |
| Operating Temperature |
-4°F to 122°F (-20°C to 50°C) |
| Communication |
USB, Wi-Fi, Bluetooth, RS-232 (optional) |
| Battery Life |
8 to 10 hours |
| Display |
7-inch multi-touch |
| Dimensions |
9.9 x 6.16 x 2.50 in (252 x 157 x 64 mm) |
| Weight |
3.6 lb. (1.63 kg) with internal rechargeable battery
2.6 lb. (1.18 kg) without battery |
