Fluke Ti25 Thermal Imager, 9 Hz
Enlarge Image
Fluke Ti-25
Request Quote Print Page

The Fluke Ti25 9 Hz thermal imager is a handheld imaging camera used for predictive maintenance, equipment troubleshooting, and verification. The Fluke Ti25 produces thermal and visual images on a 640 x 480 display. Thermal and visual images are displayed on the Imager LCD and can be saved to an SD Memory card. Transferring images to a PC is accomplished by removing the SD memory card and connecting it to a PC through the included card reader. SmartView™ software is included for image analysis and report generation from these saved images.

Both thermal and visual images can be presented simultaneously as a full fusion (thermal displayed over visual) image or as a Picture-In-Picture (PIP) image. The thermal image temperature range starts at -20°C, and goes up to +350°C.

Imager power is supplied by a rechargeable Nickel Metal-Hydride battery. A full visual image (640 x 480) can be displayed and stored with each IR image. The Ti25 also provides voice recording for annotating saved images.
Fluke Ti-25 Specs
Fluke Ti25 Temperature
Temperature measurement range (not calibrated below -10 °C) -20 °C to +350 °C (-4 °F to + 662 °F) (two ranges)
Accuracy ± 2 °C or 2% (whichever is greater)
On-screen emissivity correction Yes
Fluke Ti25 Imaging performance
Field of view 23° x 17°
Spatial resolution (IFOV) 2.5 mRad
Minimum focus distance Thermal lens: 15 cm (6 in)
Visible (visual) light lens: 46 cm (18 in)
Focus Manual
Image frequency 9 Hz refresh rate
Detector type 160 x 120 focal plane array, uncooled microbolometer
Infrared lens type 20 mm F = 0.8 lens
Thermal sensitivity (NETD) ≤0.1 °C at 30 °C (100 mK)
Infrared spectral band 7.5 µm to 14 µm
Visual camera 640 x 480 resolution
Fluke Ti25 Image presentation
Palettes Ironbow, blue-red, high contrast, amber, hot metal, grey
Level and span Smooth auto-scaling and manual scaling of level and span
Minimum span (in manual mode) 2.5 °C (4.5 °F)
Minimum span (in auto mode) 5 °C (9 °F)
IR-Fusion® information Full infrared with MAX, MID, or MIN automatic blending; and picture-in-picture with MAX, MID, or MIN automatic blending (Visual and IR blending)
Picture-In-Picture (PIP) Three levels of on-screen IR blending displayed in center 320 x 240 pixels
Full screen (PIP off) Three levels of on-screen IR blending displayed in center 640 x 480 LCD
Fluke Ti25 Voice annotation
Voice annotation 60 seconds maximum recording time per image
Fluke Ti25 Image and Data Storage
Storage medium SD memory card (2 GB memory card will store at least 1200 fully radiometric (.is2) IR and linked visual images each with 60 seconds voice annotations or 3000 basic (.bmp) IR images)
File formats Non-radiometric (.bmp) or fully-radiometric (.is2)
No analysis software required for non-radiometric (.bmp) files
Export file formats w/SmartView™ software JPEG, BMP, GIF, PNG, TIFF, WMF, EXIF, and EMF
