Keysight 8990B RF Peak Power Analyzer | 50 MHz – 40 GHz
The Keysight 8990B RF Peak Power Analyzer has an operating frequency from 50 MHz to 40 GHz. This model offers dual RF and video channels for comprehensive dynamic power analysis and a high 100 MSa/s sampling rate, ensuring detailed signal trace inspection for optimal design refinement. Formerly recognized as the Agilent 8990B, the Keysight 8990B RF Peak Power Analyzer continues to set the benchmark for peak power measurement excellence.
| RF Input Channels | 2 |
| Video Input Channels | 2 |
| Maximum Real Time Sampling Rate | 100 MSa/s (Real Time), 1 GSa/s (ETS On), 20 GSa/s |
| Maximum Capture Length | 1 s |
| Memory Depth | max 2M points |
| Instrumentation Linearity | ± 0.8% |
| Rise Time / Fall Time | ≤ 5 nsec (for frequencies ≥ 500 MHz) |
| Frequency Range | 50 MHz to 40 GHz |
| Dynamic Range | –35 dBm to +20 dBm |
| Video Bandwith | 160 MHz |
| Minimum Pulse Width | 50 ns |
| Maximum Pulse Repetition Rate | 10 MHz |
| Input Coupling | 50 Ω |
| Offset | ± 99 dBm with 0.01 dB resolution |
| ETS Threshold | 500 ns, 1 µs, 2 µs, 5 µs, 10 µs |
| Dimensions (W x D x H) | 16.9 in x 13.7 in x 13 in |
| Weight | 35 lbs |
- 160 MHz video bandwidth
- 100 MSa/ sec continuous sampling with >1500 readings/ sec
- Frequency range of 50 MHz to 40 GHz (sensor dependent)
- Fast System Rise/ Fall time of 5nsec
- 15 measurement parameters: Rise time, fall time, pulse width, duty cycle, PRI, PRF, Peak, average, peak-to-average ratio, CCDF etc.
- Automated delay measurement, automated droop measurement, pulse spacing measurement
- Multi-pulse analysis (with option 8990B-1FP or N6903A)
- Power-added efficiency (PAE) measurement
- IEC 61326-2-1:2005/EN 61326-2-1:2006
- CISPR 11:2003/EN 55011:2007 (Group 1, Class A)
- Canada: ICES-1:2004
- Australia/New Zealand: AS/NZS CISPR 11:2004
- EN61010-1: 2001/IEC 61010-1:2001
- CAN/CSA C22.2 No. 61010-1-04
- ANSI/UL std No. 61010-1-2004
