Datasheet Accessory Kit
The N1912A P-Series dual channel power meter is a LXI Class-C-compliant instrument, developed using LXI Technology. LXI, an acronym for LAN eXtension for Instrumentation, is an instrument standard for devices that use the Ethernet (LAN) as their primary communication interface.

The N1912A power meter is an easy-to-use instrument especially with the usage of an integrated Web browser that provides a convenient way to configure the instrument’s functionality.


N1912A Specifications:


  • Maximum sampling rate: 100 Msamples/sec, continuous sampling
  • Video bandwidth: ≥ 30 MHz
  • Single-shot bandwidth: ≥ 30 MHz
  • Rise time and fall time: ≤ 13 ns (for frequencies ≥ 500 MHz)
  • Minimum pulse width: 50 ns3
  • Overshoot: ≤ 5 %2
  • Average power measurement accuracy:
    • N1921A: ≤ ± 0.2 dB or ± 4.5 %4
    • N1922A: ≤ ± 0.3 dB or ± 6.7 %
  • Dynamic range:
    • –35 dBm to +20 dBm (> 500 MHz)
    • –30 dBm to +20 dBm (50 MHz to 500 MHz)
  • Maximum capture length 1 second
  • Maximum pulse repetition rate 10 MHz (based on 10 samples per period)
