The LeCroy WaveSurfer 104MXS-B Digital Oscilloscope 1 GHz is a four-channel digital oscilloscope with a maximum real-time sample rate of 5GS/s per channel (10GS/s interleaved), a record length of 16 Mpts per channel (32 Mpts interleaved), advanced triggering, WaveScan search, 23 measurement parameters, 18 math functions, an internal memory for data storage, and USB connectivity for electronics applications such as product design, serial data testing, disk drive testing, and automotive bus analysis, among others. The high sample rate and deep memory enable long capture times for processing and displaying detailed waveforms even when measurement parameters and math functions are engaged. In addition to edge triggering, the unit has glitch, width, logic (pattern), TV (NTSC, PAL, SECAM, HDTV), runt, slew rate, interval, dropout, and qualified triggers for isolating a specific signal as well as a trigger hold-off function that stabilizes triggering on complex but repetitive waveform memory of the oscilloscope.
LeCroy 104MXS-B Specs
Bandwidth: 1GHz
Channels: Four
Maximum real-time sample rate: 5GS/s per channel, 10GS/s interleaved
Record length: 16 Mpts per channel, 32 Mpts interleaved
Installation rating: CAT II, 300V
Standards met: EN 61010-1:2010 and 61010-2:030:2010, UL 61010-1, and CAN/CSA-C22.2 No. 61010-1-12 safety standards
