LeCroy WaveRunner 104MXi Oscilloscope

Need Help? Call (800) 404-2832ATEC AssuranceWorldwide Delivery
Rent LeCroy WaveRunner 104MXi Oscilloscope
Enlarge Image
LeCroy 104MXi
Request Quote Print Page
104MXi Datasheet
The LeCroy WaveRunner 104MXi with its advanced triggers, fast viewing modes, measurment parameters, and serial decodes make validation and simple and easy. Advanced debug, multi-domain analysis, and waveshape analysis are possible with tools unique to WaveRunner Xi. Building on the features and capabilities of the WaveRunner Xi the WaveRunner 104MXi provides a higher level of analysis, measurement and customization tools, making it the most powerful and capable oscilloscope in its class.

The collection of tools, features an functions packed into this small 6" deep instrument with large 10.4" touch screen make the WaveRunner 104MXi a truly unique oscilloscope. With a maximum sampling rate of 10 GS/s (5 GS/s per channel) you can be confident in all your measurements knowing that even the fastest signals in your device are being captured. High sample rate is important for fast signals and edges but without long memory this rate cannot be maintained for long captures. The 25 Mpts (12.5 Mpts/Ch) fast memory guarantees maximum sample rate for 2.5 ms.
LeCroy 104MXi Features
  • 1 GHz Analog Bandwidth
  • 5 GS/s per Channel (10 GS/s Max.)
  • Long Capture Time with 12.5 Mpts/Ch memory
  • WaveScan Advanced Search Feature
  • LabNotebook Report Generation Tool
  • Advanced Math and Measurement Capabilities
  • Jitter and Timing Analysis
  • Customized Math and Measurements
  • Powerful SMART Triggers
  • HDTV Trigger
  • Large 10.4" Touch Screen
  • Small 6" Deep Footprint
  • Mixed Signal Options
  • I2C, SPI, UART and RS-232 Trigger and Decode
  • CAN, LIN and FlexRay Trigger and Decode
