Combining Teledyne LeCroy’s HD4096 high definition 12-bit technology, with long memory, a compact form factor, 12.1” touch screen display, powerful measurement and analysis tools, and mixed signal capability, the Teledyne LeCroy HDO6034 High Definition Oscilloscope 350 MHz, 2.5 GS/s is the ideal oscilloscope for circuit validation, system debug and waveform analysis. The powerful feature set provides analytical tools and unique application packages to streamline the testing process. Tools such as WaveScan Search and Find and History Mode, combined with advanced triggering, identify and isolate problems while Spectrum Analyzer Mode provides analysis tools in the frequency domain.

Teledyne LeCroy HDO6034 Features:


  • 12-bit ADC resolution, up to 15 bits with enhanced resolution
  • 350 MHz bandwidth
  • Long Memory – up to 250 Mpts/Ch
  • 12.1” touch screen display
  • Spectrum Analyzer Mode
  • WaveScan – Advanced Search and Find
  • History Mode – Waveform Playback
  • Power Analysis Software
  • JITKIT Clock-Data Jitter Analysis
  • Serial Data Trigger and Decode
  • PROTObus MAG Serial Data Debug Toolkit
  • LabNotebook Report Generation
  • Advanced Trigger Tools including TriggerScan and Software Assisted Trigger
  • 16 Digital Channels with 1.25 GS/s Sample Rate
  • Mixed Signal Debug Capabilities
    • Analog and Digital Cross Pattern Triggering
    • Digital Pattern Search and Find
    • Analog and Digital Timing Measurements
    • Logic Gate Emulation
