Sorensen DCR40-60A 0-40V 0-60A DC Power Supply

Rent Sorensen DCR40-60A 0-40V 0-60A DC Power Supply
Enlarge Image
Request Quote Print Page
Manual Datasheet

Specifications:

  • Output Voltage (Vdc): 0 - 40
  • Output Current (Adc): 0 - 60
  • Constant Voltage Regulation: ± .075% or ± 15mV³
  • Constant Current Range (Adc): 0 - 60
  • Constant Current Regulation: ± 60mA
  • Constant Voltage Ripple: .4% + 40mV
  • Constant Current Ripple (Typ): 0.5%
  • Temperature:
    Ambient (°C): 0 - 55
    Coef. MV/°C: 6
  • Typical Efficiency %: 66
  • Input Voltage 1 phase (Vac): 187-229, 207-253
  • Dimensions (inches): 19 W x 7 H x 20 D
  • Weight (lbs): Net: 131
