Parameter
Specification
Notes
Operating Frequency Range
26.5 – 40.0 GHz
Power Output @ Psat
200 W Min/250 W Typ
CW or Pulse
Power Output @ P1dB
140 W Typ
Power Gain
53 dB Min
0dBm or less for rated Pout
Power Gain Flatness
4.0 dB p-p Typ
Constant input power
Operating Voltage
230/380 VAC, 3 ph
Power Consumption
8000 W Max
At rated Pout
Dimensions (W x H x D)
19 in x 21 in x 31 in)
12U, excluding connectors
RF Conn. In / Out / Sample (Optional)
(2.92) K-Female / WR28 / (2.92) K-Female
Rear panel
Interface Connector
9-Pin D-Sub
Weight (Typical)
99.2 lb.
