AEM TestPro CV100-K61 Copper and Fiber Certification Kit

Larger

Categories

Documents

Datasheet

The AEM TestPro CV100-K61 Copper and Fiber Certification Kit is a multifunction cable tester that's made for a vast range of networks and materials. The TestPro CV100-K61 offers a more sophisticated RF measurement engine than any other handheld device. The cable tester has a frequency range that reaches 3 GHz and surpasses level 2G accuracy specifications for all copper certification testing.

Fiber optic certification testing is also possible with the AEM TestPro CV100-K61. The tester has Tier-1 certification that's based off industry standards, plus a fiber optic inspection feature to ensure fiber end faces are clean and ready for installation. An autotest feature also allows users to ensure a preferred network rate from cabling links and PoE testing to meet every standard.

Beyond a multifunction cable tester, the AEM TestPro CV100-K61 comes with a variety of adapters to meet all testing needs. The copper and fiber certification kit includes the following test adapters to go along with standard components:

Set of AD-CAT6A-CH Channel Adapters
Set of AD-CAT6A-PL Permanent Link Adapters
Set of AD-NET-CABLE Adapters for PoE and Multi-Gigabit
Set of AD-SM-01 SingleMode Fiber Optic Adapters
Set of AD-MM-01 MultiMode Fiber Optic Adapters

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Approximate test time	8 hours
RJ45 test ports	10/100/1G test port
Adapter interface	60-pin high-frequency connector Rated for 5000 insertion cycles

Copper Testing
CAT 6A measurement time	6 seconds
CAT 8 class II auto-test measurement time	30 seconds
DC resistance range	0 to 50Ω
Tone generator	730Hz and 1440Hz
TDR-RL	0-100m
TDR-NEXT	0-100m
Impedance	0-1000Ω

Fiber Optic
VFL light source	Wavelength 650nm
Voltmeter measurement range	0-60V DC
Optical power meter measurement range	-3 dBm to -30 dBm
