| Model |
OptiFiber Pro:
OFP2-100-M (850, 1300 nm)
OFP2-100-S (1310, 1550 nm)
OFP2-100-Q (850, 1300, 1310, 1550 nm) |
OptiFiber Pro HDR:
OFP2-200-S (1310, 1550 nm)
OFP2-200-S1490 (1310, 1490, 1550 nm)
OFP2-200-S1625 (1310, 1550, 1625 nm) |
| Application |
Enterprise, Datacenter, Campus |
FTTx, Outside Plant, PON, POLAN, Access |
| Wavelengths |
850 nm
1300 nm
1310 nm
1550 nm |
1310 nm
1490 nm
1550 nm
1625 nm |
| Compatible fiber types |
50/125 µm, 62.5 µm, Singlemode |
Singlemode |
| OTDR Port Connector |
Cleanable UPC ferrule with removable SC adapter |
Cleanable APC ferrule with removable SC adapter |
| Supplied Test Cords |
Launch Fibers for testing LC systems |
2m TRC for testing SCAPC systems |
| OTDR types |
Auto, Datacenter, Manual |
Auto, Auto PON, Manual, Manual PON |
| Event Dead Zone |
850 nm: 0.5 m (typical),
1300 nm: 0.7 m (typical),
1310 nm: 0.6 m (typical),
1550 nm: 0.6 m (typical) |
1310 nm: 0.7 m (typical),
1490 nm: 0.7 m (typical),
1550 nm: 0.7 m (typical),
1625 nm: 0.7 m (typical) |
| Attenuation Dead Zone |
850 nm: 2.5 m (typical),
1300 nm: 4.5 m (typical),
1310 nm: 3.6 m (typical),
1550 nm: 3.7 m (typical) |
1310 nm: 4 m (typical),
1490 nm: 4 m (typical),
1550 nm: 4 m (typical),
1625 nm: 4 m (typical) |
| PON Dead Zone |
N/A |
30 m (typical) |
| Dynamic Range |
850 nm: 28 dB (typical)
1300 nm: 30 dB (typical)
1310 nm: 32 dB (typical)
1550 nm: 30 dB (typical) |
1310 nm: 42 dB (typical)
1490 nm: 41 dB (typical)
1550 nm: 41 dB (typical)
1625 nm: 40 dB (typical) |
| Reflectance range |
850 nm: -14 dB to -57 dB (typical),
1300 nm: -14 dB to -62 dB (typical),
1310 nm: -14 dB to -65 dB (typical),
1550 nm: -14 dB to -65 dB (typical) |
1310 nm: -14 to -70 dB (typical),
1490 nm: -14 dB to -70 dB (typical),
1550 nm: -14 dB to -70 dB (typical),
1625 nm: -14 dB to -70 dB (typical) |
| Sampling Resolution |
Up to 64,000 |
Up to 129,000 |
| Expert Manual Mode |
Yes |
Yes |
| SmartLoop with on-board |
Yes |
Yes |
| Macrobend detection |
Yes |
Yes |
| Span Support |
Available early 2019 |
| Event editing and additions |
Available early 2019 |
| VFL |
Yes |
Yes |
