Dimensions
(without PC and monitor: W x L x H) |
Standard base: 407 x 770 x 305 mm (16 x 30.3 x 12")
Wide standard base: 610 x 1037 x 305 mm (24 x 40.8 x 12”)
Mini-well base: 407 x 770 x 400 mm (16 x 30.3 x 15.7")
XY motorised base: 610 x 1037 x 375 mm (24 x 40.8 x 14.8") |
| Weight (without PC and monitor) |
97 kg |
| Element range |
Aluminium13 to Uranium92 |
| Number of layers and elements |
4 layers + base
Composition analysis of up to 25 elements simultaneously |
| X-ray excitation |
50 W (50 kV and 1.0 mA) micro-focused tungsten anode tube |
| X-ray detector |
High resolution silicon drift detector (SDD) |
| Working environment |
10°C (50°F) to 40°C (104°F) and up to 98% relative humidity, non-condensing |
| Power supply |
85 - 130 or 215 - 265 volts, with frequency range of 47 Hz to 63 Hz |
| Configurations |
Standard base (for parts up to 16 mm / 0.63" in height)
Wide standard base (for parts to 16 mm / 0.63" in height)
Fixed table size: 560 x 610 mm (22” x 24”)
Mini-well base (for parts up to 143 mm / 5.6" in height)
XY programmable table
Table travel: 178 mm x 178 mm (7" x 7")
Z travel on all configurations: 19 mm (0.75")
Slotted chamber on all configurations |
