X-Ray Specifications |
Dectector |
High count rate, high resolution
Extra large area silicon drift detector (1μm graphene window) |
Spot Size |
8mm collimation |
Analytical Range |
Mg-U (ultra low light element detection)
Na (spectrum based detection) |
Calibration Modes |
- General Metals
- Precious Metals
- Coatings
- Mining
- Soils
- Electronic Alloys
- Plastics
- Industial Lead in Paint
- Spectral Fingerprint
- TestAll™
|
Libraries |
Default Alloy Libraries based on SAE, AISI, ASTM, AA, DIN, GB standards |
