Olympus Delta Handheld XRF Analyzer

The Olympus Delta Handheld XRF Analyzer offers rapid and non-destructive elemental analysis with a broad detection range from magnesium to uranium. Its rugged design and intuitive touchscreen interface makes it ideal for field use in industries such as mining, manufacturing, and environmental testing. The analyzer features a Silicon Drift Detector (SDD) for high-resolution results and includes data storage with USB, Wi-Fi, and Bluetooth connectivity for easy data management. With an integrated camera and long battery life, the Delta XRF Analyzer provides reliable performance for on-site material verification and analysis.

Product Info Related Products

Excitation Source:	4W Au or Ta anode X-ray tube
Detector:	Si-PIN Diode
Environmental Temperature Range:	-10 ºC to 50 ºC (14 ºF to 122 ºF)
Analytical Range:	Alloy and Mining: Ti and higher; Soil: P and higher
Processing Electronics:	530 MHz CPU with integrated FPU with 128 MB RAM; Proprietary Olympus Digital Pulse Processor (DPP)
Smart Electronics:	Accelerometer; Barometer for atmosphere pressure correction of light elements’ measurements

Powerful 4W X-ray tube, 200 μA current (max), optimized beam settings.
Tight geometry for exceptional LODs and high analysis throughput.
Large-Area SDD and customized X-ray tube options for exceptional sensitivity and precision for more elements and materials.
Patent-pending automatic barometric pressure correction that adjusts calibration as needed for more accurate analysis of light element.
Lightning-fast data acquisition for faster testing time
Floating Point Processor: Provides more calculations in less time, and leverages more advanced calibration algorithms.
Integrated Bluetooth® for data input and output available in most countries.
