| Output voltage |
Air discharge: 1 kV to 30 kV, 100V steps
Contact discharge: 1 kV to 30 kV, 100V steps |
| Polarity of the output voltage |
Positive and negative |
| Test modes |
Air and contact discharge |
| Repetition frequency of the discharge pulses |
Air discharge: single pulse or repeated
Contact discharge: single pulse, 0.1 Hz, 0.2 Hz, 1 Hz, 2 Hz, 5 Hz, 10 Hz, 20 Hz |
| Permanent operation |
possible at air- and contact discharge |
| Pre-selectable counter |
1 - 9999 |
| Probes |
in conformity with IEC / EN 61000-4-2 and ISO / TR 10605 |
| Energy storage capacity |
150 pF ± 10% |
| Discharge resistor |
330 Ohm ± 5% |
| Operation temperature range |
0 - 40° Celsius |
| Relative humidity |
0 - 60% |
| Weight |
app. 1500 g |
| Desktop control unit voltage |
85 - 264 VAC, 47 - 63 Hz |
| Desktop control unit weight |
app. 1450 g |
