The M Precision Laboratories MiniZap MZ-15/EC ESD Simulator operates over a frequency range of .5 to 15 kV in air discharge mode and can be used for direct, indirect and diagnostic ESD testing. With the MiniZap, manufacturers of computers and other semiconductor-based equipment can implement meaningful, dependable, company-wide ESD simulation testing with results that correlate throughout the industry. The M Precision Laboratories MiniZap MZ-15/EC ESD simulator generates simulation pulses, which are repeatable and correctable. This test instrument is integrated into one light-weight, hand-held unit that can be easily stored in any standard tool kit. By interchanging plug-in tips, the MiniZap MZ-15/EC ESD simulator allows you to meet both the IEC 61000-4-2 standard's 0.7 to 1.0 ns risetime, and to generate a <200ps ESD risetime.
The M Precision Laboratories MZ-15/EC MiniZap was previously the Thermo Fisher Scientific Keytek MZ-15/EC MiniZap ESD Simulator.
Features
- Intuitive operation.
- Portable & self-contained.
- Meets exact requirements of IEC 61000-4-2.
- Contact mode & air discharge ESD testing.
- Generates real world, repeatable & correlatable ESD pulses.
- E & H Field diagnostics.
- Vertical & horizontal coupling planes for indirect ESD testing.
- Built-in safety features.
- Field-configurable.
- Rechargeable battery or AC powered.
Specifications
Contact Mode Voltage Range |
±0.5 to >8 kV |
Air Discharge Voltage Range |
±0.5 to 15 kV |
Air Discharge |
TRUE-ESD (<0.3 ns nominal risetime up to 4 kV) |
Contact Mode |
FR/CI standard |
RC Networks3: |
150 pF/330 ohms standard |
Lock On |
Standard |
Rep Rate |
Single shot, 1/sec & 20/sec repetitive operation |
HV Display |
Digital LCD display measures actual HV at the tip with 10V resolution, ~3% accuracy |
